Scenario Applications
- Commercial settings: Office building plazas, corporate campuses, hotel lobbies, sales centers, etc.
- Cultural & tourism settings: Cultural plazas, parks and scenic areas, campuses, exhibition halls, etc.
- Private settings: Villa courtyards, private clubs, art galleries, etc.
- Suitable environments: Open-air outdoors, indoor climate-controlled spaces, seaside/high-salinity environments (rust-resistant specifications), etc.
|
 |
Process Details
- A 1:1 scale model is first produced from ABS material using 3D printing technology. For the sculpture’s surface, 2.0mm-thick 304 stainless steel sheets are marked and cut based on the model; the metal is then shaped through manual forging—involving approximately 3,000 hammer strikes per square meter—followed by seamless welding of the sections. Flat steel components are precision-cut via laser based on Rhino software designs and assembled. The subsequent mirror-polishing process begins with grinding down weld seams and forging marks using 80-grit sandpaper, followed by progressive smoothing with sandpaper grits of 120, 320, 600, 800, 1200, and 2000. A sisal wheel with purple polishing compound is used to remove initial grinding marks, followed by a wool wheel to eliminate marks left by the sisal wheel. Finally, a cloth wheel with green and white polishing compounds is used for the finishing polish to achieve a mirror-like surface. Internally, a galvanized square-tube framework is installed to match the sculpture’s dimensions, enhancing wind and seismic resistance, with anti-rust treatment applied to all weld joints.
|
 |
Design Philosophy
- Infinite Flow
Centered on continuous, looping curves, the design simulates a trajectory with neither beginning nor end, evoking a sense of spatial and temporal extension.
- Minimalist Order
By stripping away superfluous structural details and retaining only the purest tension of curved surfaces, the form embodies a highly unified modern sculptural aesthetic.
- Spatial Reflection
The mirror-finish stainless steel interacts dynamically with the surroundings, transforming the sculpture into a link connecting the site, the light, and the viewer.
|
 |
Transport and Installation
- Protective Packaging: Reinforced wooden crates with EPE foam padding on all edges and corners to prevent impact and scratches;large sculptures can be disassembled for packaging;
- Logistics Options: Sea, air, and land transport available; supports both FCL (Full Container Load) and LCL (Less than Container Load) shipments;
- Installation Support: Includes embedded base, expansion anchor bolts, and leveling accessories; comprehensive printed installation diagrams provided;
- Ancillary Services: On-site installation teams available; free replacement of repair materials for transit damage; shipping insurance coverage available.
|
 |
Customization Time
- Drawing approval period: 3–5 working days;
- Main forging production: 10–20 days (depending on sculpture size);
- Surface finishing and quality inspection: 3–7 days;
- Packaging and preparation: 2 days;
- Value-added service: Production time for rush orders can be shortened for a small additional fee.
|
